- Product Description
- Commodity name: TG50209SNGX
- Commodity ID: 1131280623512211456
P/N TG50209SNGX Product Description Lan transformer, SMT Number of Ports Dual Speed 2.5&5G POE Rating POE++ Rev A0
2.Designed to meet IEEE802.3at requirements;
3.Storage Temperature:-40℃ To +85℃,Operating Temperature:-40℃ To +85℃;
4.SRP: Conforms to IPC/JEDEC J-STD-020;
5.Solderability:Conforms to ANSI/J-STD-002;
6.Packaging with tapes and reels.
Electrical Specification at 25℃ Parameter Specifications OCL 150uH Min(100KHz,0.1V) LL 0.35uH Max(100KHz,0.1V) Turns Ratio 1:1±5% DCR 1.2Ω Max Hi-Pot PRI To SEC(1500Vrms 1mA 60Sec) Insertion Loss 1-100MHz 125MHz 250MHz -1.0dB Max -1.5dB Max -2.5dB Max Return Loss 1-40MHz 40-125MHz 250MHz -16dB Min -16 +10*LOG(f/40) -6.0dB Min Cross Talk 1-10MHz 100MHz 125MHz -50dB Min -30dB Min -25dB Min Common Mode Rejection 1-100MHz 100-250MHz -30dB Min -22dB Min Schematic Dimensions
