- Product Description
- Commodity name: DG24123SKGX
- Commodity ID: 1131280599151693824
P/N DG24123SKGX Product Description Lan transformer, SMT Number of Ports Single Speed 2.5&5G POE Rating POE++ Rev A0
2.Designed to meet IEEE802.3bt requirements;
3.Storage Temperature:-40℃ To +85℃,Operating Temperature: -40℃ To +85℃;
4.SRP: Conforms to IPC/JEDEC J-STD-020;
5.Solderability:Conforms to ANSI/J-STD-002;
6.Packaging with tapes and reels.
Electrical Specification at 25℃ Parameter Specifications OCL 150uH Min(100KHz,0.1V) LL 0.35uH Max(100KHz,0.1V) Turns Ratio 1:1±5% DCR 1.4Ω Max Hi-Pot PRI To SEC(1500Vrms 1mA 60Sec) Insertion Loss 1-100MHz 100-250MHz -1.0dB Max -2.0dB Max Return Loss 1MHz 40MHz 80MHz 160MHz 200MHz 250MHz -16dB Min -16dB Min -12.99dB Min -9.98dB Min -9.01dB Min -8.04dB Min Cross Talk 1-30MHz 100MHz 250MHz -38dB Min -30dB Min -22dB Min Common Mode Rejection 1-100MHz 100-250MHz -30dB Min -25dB Min Schematic Dimensions
