- Product Description
- Commodity name: G24101SCGX
- Commodity ID: 1131280487759368192
P/N G24101SCGX Product Description Lan transformer, SMT Number of Ports Single Speed 1000BASE-T POE Rating POE Rev A0
2. Designed to meet IEEE802.3af requirements;
3.Storage Temperature:-40℃ To +85℃,Operating Temperature:-40℃ To +85℃;
4.SRP: Conforms to IPC/JEDEC J-STD-020;
5.Solderability:Conforms to ANSI/J-STD-002;
6.Packaging with tapes and reels.
Electrical Specification at 25℃ Parameter Specifications OCL 350uH Min(100KHz,0.1V With 8mA DC Bias) LL 0.5uH Max(100KHz,0.1V) Turns Ratio 1:1±5% DCR 1.4Ω Max Hi-Pot PRI To SEC(1500Vrms 1mA 60Sec) Insertion Loss -1.1dB Max(1-100MHz) Return Loss 1-40MHz 40-100MHz -16dB Min -16 +20 *LOG(f/40) Cross Talk -30dB Min(1-100MHz) Common Mode Rejection -30dB Min(1-100MHz) Schematic Dimensions
